NCV8502D33R2G

Micropower 150 mA, LDO Linear Regulators, 8-SOIC, -15 to 48 V, Thermal Overload

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.65~0.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.65~0.70

PartNumber:: NCV8502D33R2G

Brand:: ON Semiconductor - ON | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sophia's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-29

From Other Seller

Part Number:NCV8502D33R2G
US $0.65 - 0.70
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The NCV8502D33R2G is a precision micropower voltage regulator. Their output current capability is 150 mA. TheNCV8502D33R2G has output voltage options for adjustable, 2.5 V, 3.3 V, 5.0 V, 8.0 V, and 10 V. The output voltage is accurate within ±2.0% with a maximum dropout voltage of 0.6 V at 150 mA. Low quiescent current is a feature drawing only 90 uA with a 100 uA load. This part is ideal for any and all battery operated microprocessor equipment. The regulator NCV8502D33R2G is protected against reverse battery, short circuit, and thermal overload conditions. The device can withstand load dump transients making it suitable for use in automotive environments. The NCV8502D33R2G has also been optimized for EMC conditions.

Parametrics

NCV8502D33R2G maximum ratings: (1)VIN (dc): -15 to 48 V; (2)Peak Transient Voltage (46 V Load Dump @ VIN = 14 V): 60 V; (3)Operating Voltage: 45 V; (4)VOUT (dc): -0.3 to 16 V; (5)Voltage Range (RESET, FLAG): -0.3 to 10 V.

Features

NCV8502D33R2G features: (1)Output Voltage Options: Adjustable, 2.5 V, 3.3 V, 5.0 V, 8.0 V, 10 V; (2)±2.0% Output; (3)Low 90 uA Quiescent Current; (4)Fixed or Adjustable Output Voltage; (5)Active RESET; (6)Adjustable Reset; (7)150 mA Output Current Capability; (8)Fault Protection: +60 V Peak Transient Voltage; -15 V Reverse Voltage; Short Circuit; Thermal Overload; (9)Early Warning through FLAG/MON Leads; (10)NCV Prefix for Automotive and Other Applications Requiring Site and Change Control; (11)AEC Qualified; (12)PPAP Capable; (13)These are Pb-Free Devices.
