Product Summary

LP2996MX is a DDR Termination Regulator. It is designed to meet the JEDEC SSTL-2 specifications for termination of DDR-SDRAM. The device contains a high-speed operational amplifier to provide excellent response to load transients.

Parametrics

LP2996MX absolute maximum ratings: (1)PVIN, AVIN, VDDQ to GND:-0.3V to +6V; (2)Storage Temp. Range:-65℃ to +150℃; (3)Junction Temperature:150℃; (4)SO-8 Thermal Resistance (θJA):151℃/W; (5)Lead Temperature (Soldering, 10 sec):260℃; (6)ESD Rating:1kV.

Features

LP2996MX features: (1)Source and sink current; (2)Low output voltage offset; (3)No external resistors required; (4)Linear topology; (5)Suspend to Ram (STR) functionality; (6)Low external component count; (7)Thermal Shutdown; (8)Available in SO-8, PSOP-8 or LLP-16 packages.

Diagrams

LP2996MX block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LP2996MX
LP2996MX

National Semiconductor (TI)

Low Dropout (LDO) Regulators

Data Sheet

0-2500: $0.52
2500-5000: $0.46
5000-10000: $0.44
LP2996MX/NOPB
LP2996MX/NOPB

National Semiconductor (TI)

Low Dropout (LDO) Regulators

Data Sheet

0-1: $0.81
1-10: $0.73
10-25: $0.65
25-100: $0.44
