Product Summary

The MC3403DR2G is a low cost, quad operational amplifier with true differential inputs. The device has electrical characteristics similar to the popular MC1741C. However, the MC3403DR2G has several distinct advantages over standard operational amplifier types in single supply applications. The quad amplifier can operate at supply voltages as low as 3.0 V or as high as 36 V. The output voltage range of the MC3403DR2G also includes the negative power supply voltage.

Parametrics

MC3403DR2G absolute maximum ratings: (1)Power Supply Voltages: Single Supply, 36V; Split Supplies, ±18V; (2)Input Differential Voltage Range (Note 1): ±36 V; (3)Input Common Mode Voltage Range (Notes 1 and 2): ±18 Vdc; (4)Storage Temperature Range: 55 to +125 ℃; (5)Operating Ambient Temperature Range: 0 to +70℃; (6)Junction Temperature: 150℃.

Features

MC3403DR2G features: (1)Short Circuit Protected Outputs; (2)Class AB Output Stage for Minimal Crossover Distortion; (3)True Differential Input Stage; (4)Single Supply Operation: 3.0 V to 36 V; (5)Split Supply Operation: ±1.5 V to ±18 V; (6)Low Input Bias Currents: 500 nA Max; (7)Four Amplifiers Per Package; (8)Internally Compensated; (9)Similar Performance to Popular MC1741C; (10)Industry Standard Pin-outs; (11)ESD Diodes Added for Increased Ruggedness; (12)Pb-Free Packages are Available.

Diagrams

MC3403DR2G schematic diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MC3403DR2G
MC3403DR2G

ON Semiconductor

Operational Amplifiers - Op Amps 3-36V Quad 10mV VIO Commercial Temp

Data Sheet

0-1: $0.32
1-25: $0.29
25-100: $0.23
100-500: $0.19
