Product Summary
The TDA7052BT is 0.5W mono Bridge-Tied Load (BTL) output amplifier with DC volume control. It has been designed for use in TV and monitors, but is also suitable for use in battery-fed portable recorders and radios.
Parametrics
TDA7052BT absolute maximum ratings: (1)supply voltage, VP: 18V; (2)input voltage pins 2 and 4, V2, 4: 5V; (3)repetitive peak output current, IORM: 1.25A; (4)non-repetitive peak output current, IOSM: 1.5 A; (5)operating ambient temperature, Tamb: -40 to +85℃ (6)storage temperature, Tstg: -55 to +150℃; (7)virtual junction temperature, Tvj: +150℃; (8)short-circuit time, Tsc: 1h.
Features
TDA7052BT features: (1)DC volume control; (2)Few external components; (3)Mute mode; (4)Thermal protection; (5)Short-circuit proof; (6)No switch-on and switch-off clicks; (7)Good overall stability; (8)Low power consumption; (9)Low HF radiation; (10)ESD protected on all pins.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TDA7052BT/N1,112 |
NXP Semiconductors |
Audio Amplifiers 0.5W BTL MONO AMP |
Data Sheet |
|
|
||||||||||||
|
TDA7052BT/N1,118 |
NXP Semiconductors |
Audio Amplifiers POWER AMPLIFIER |
Data Sheet |
|
|
||||||||||||
|
TDA7052BTD |
NXP Semiconductors |
Audio Amplifiers 0.5W BTL MONO AMP W/VOL CTRL |
Data Sheet |
Negotiable |
|
||||||||||||
