Product Summary

The LM2575HVS-ADJ is a regulator. It provides all the active functions for a step-down (buck) switching regulator, capable of driving a 1A load with excellent line and load regulation. The LM2575HVS-ADJ is available in fixed output voltages of 3.3V, 5V, 12V, 15V, and an adjustable output version. The LM2575HVS-ADJ offers a high-efficiency replacement for popular three-terminal linear regulators. It substantially reduces the size of the heat sink, and in many cases no heat sink is required.

Parametrics

LM2575HVS-ADJ absolute maximum ratings: (1)Power Dissipation: Internally Limited; (2)Storage Temperature Range: -65 to +150℃; (3)Maximum Junction Temperature: 150℃; (4)Minimum ESD Rating (C = 100 pF, R = 1.5 kΩ): 2 kV; (5)Lead Temperature (Soldering, 10 sec.): 260℃.

Features

LM2575HVS-ADJ features: (1)3.3V, 5V, 12V, 15V, and adjustable output versions; (2)Adjustable version output voltage range, 1.23V to 37V (57V for HV version) ±4% max over line and load conditions; (3)Guaranteed 1A output current; (4)Wide input voltage range, 40V up to 60V for HV version; (5)Requires only 4 external components; (6)52 kHz fixed frequency internal oscillator; (7)TTL shutdown capability, low power standby mode; (8)High efficiency; (9)Uses readily available standard inductors; (10)Thermal shutdown and current limit protection; (11)P+ Product Enhancement tested.

Diagrams

LM2575HVS-ADJ Block Diagram and Typical Application

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM2575HVS-ADJ
LM2575HVS-ADJ

National Semiconductor (TI)

Switching Converters, Regulators & Controllers

Data Sheet

0-1: $3.01
1-25: $2.42
25-100: $2.20
100-250: $1.99
LM2575HVS-ADJ/NOPB
LM2575HVS-ADJ/NOPB

National Semiconductor (TI)

Switching Converters, Regulators & Controllers 1A STEP-DOWN VLTG REG

Data Sheet

0-1: $3.01
1-25: $2.42
25-100: $2.20
100-250: $1.99
