SN65HVD32DRG4

3-state differential line driver, differential-input line receiver, RS-485 Interface IC, 8-SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.30~1.33 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.30~1.33

PartNumber:: SN65HVD32DRG4

Brand:: Texas Instruments - TI | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sophia's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-29

From Other Seller

Part Number:SN65HVD32DRG4
US $1.30 - 1.33
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
STK795-810

US $12.00 - 16.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN65HVD32DRG4 is a 3-state differential line driver and differential-input line receiver that operate with 3.3V power supply. Each driver and receiver has separate input and output pins for full-duplex bus communication designs. The SN65HVD32DRG4 is designed for RS-422 and RS-485 data transmission over cable lengths of up to 1500 meters. The SN65HVD32DRG4 has active-high driver enables and active-low receiver enables. A low, less than 1mA, standby current can be achieved by disabling both the driver and receiver.

Parametrics

SN65HVD32DRG4 absolute maximum ratings: (1)Supply voltage range, Vcc: –0.3V to 6V; (2)Voltage range at any bus terminal (A, B, Y, Z), V(A), V(B), V(Y), V(Z): –9V to 14V; (3)Voltage input, transient pulse through 100 Ω. See Figure 12 (A, B, Y, Z), V(TRANS): –50 to 50V; (4)Input voltage range (D, DE, RE), VI: -0.5V to 7V; (5)Output current (receiver output only, R), IO: 11mA.

Features

SN65HVD32DRG4 features: (1)1/8 Unit-Load Option Available (Up to 256 Nodes on the Bus); (2)Bus-Pin ESD Protection Exceeds 15 kV HBM ; (3)Optional Driver Output Transition Times for Signaling Rates of 1 Mbps, 5 Mbps and 26 Mbps ; (4)Low-Current Standby Mode: < 1 mA ; (5)Glitch-Free Power-Up and Power-Down Protection for Hot-Plugging Applications; (6)5V Tolerant Inputs ; (7)Bus Idle, Open, and Short Circuit Failsafe; (8)Driver Current Limiting and Thermal Shutdown ; (9)Designed for RS-422 and RS-485 Networks ; (10)5V Devices available, SN65HVD50-55.
