Product Summary

The OPA2353UA rail-to-rail CMOS operational amplifier is designed for low cost, miniature applications. It is optimized for low voltage, single-supply operation. Rail-to-rail input/output, low noise (5nV/Hz), and high speed operation (44MHz, 22V/μs) make it ideal for driving sampling analog-to-digital converters. The OPA2353UA is also well suited for cell phone PA control loops and video processing (75Ω drive capability) as well as audio and general purpose applications. Single, dual, and quad versions have identical specifications for design flexibility. The OPA2353UA operates on a single supply as low as 2.5V with an input common-mode voltage range that extends 300mV beyond the supply rails. Output voltage swing is to within 10mV of the supply rails with a 10kΩ load. Dual and quad designs feature completely independent circuitry for lowest crosstalk and freedom from interaction.

Parametrics

OPA2353UA absolute maximum ratings: (1)Supply Voltage 5.5V; (2)Signal Input Terminals, Voltage(2) (V–) – 0.3V to (V+) + 0.3V; (3)Current(2) 10mA; (4)Output Short-Circuit(3) Continuous; (5)Operating Temperature –55℃ to +125℃; (6)Storage Temperature –55℃ to +125℃; (7)Junction Temperature 150℃; (8)Lead Temperature (soldering, 10s) 300℃.

Features

OPA2353UA features: (1)Rail-to-rail input; (2)Rail-to-rail output (within 10mV); (3)Wide bandwidth: 44MHz; (4)High slew rate: 22V/μs; (5)Low noise: 5nV/Hz; (6)Low thd+noise: 0.0006%; (7)Unity-gain stable; (8)Microsize packages; (9)Single, dual, and quad.

Diagrams

OPA2353UA circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
OPA2353UA
OPA2353UA

Texas Instruments

High Speed Operational Amplifiers Hi-Spd Single-Sply Rail-to-Rail

Data Sheet

0-1: $3.28
1-25: $2.63
25-100: $2.39
100-250: $2.16
OPA2353UA/2K5
OPA2353UA/2K5

Texas Instruments

High Speed Operational Amplifiers Hi-Spd Single-Sply Rail-to-Rail

Data Sheet

0-1850: $1.31
1850-2000: $1.27
2000-2500: $1.27
2500-5000: $1.21
OPA2353UAG4
OPA2353UAG4

Texas Instruments

High Speed Operational Amplifiers Hi-Spd Single-Sply Rail-to-Rail

Data Sheet

0-1: $2.88
1-25: $2.40
25-100: $2.11
100-250: $1.83
OPA2353UA/2K5G4
OPA2353UA/2K5G4

Texas Instruments

High Speed Operational Amplifiers Hi-Spd Single-Sply Rail-to-Rail

Data Sheet

0-1850: $1.31
1850-2000: $1.27
2000-2500: $1.27
2500-5000: $1.21
