Product Summary

The Bay Linear LM2931MX-5.0 is a low power voltage regulator designed for a wide range of applications. It is an excellent choice for use in Battery Powered applications. The LM2931MX-5.0 feature low quiescent current (100 μA Typ.) and low dropout of only 60mV at light loads and 300mV (typ.) at 100mA. The LM2931MX-5.0 has tight initial tolerance of 0.5% typ., extremely good load and line regulation of 0.05% typ. and very low output temperature coefficient. The applications of the LM2931MX-5.0 include Battery Powered Systems, Portable instrumentation, Notebooks Computers, Potable Consumer Equipment, Automotive electronics, SMPS Post-Regulator.

Parametrics

LM2931MX-5.0 absolute maximum ratings: (1)Power Dissipation: Internally Limited; (2)Lead Temperature ( Soldering 5 seconds ): 260 ℃; (3)Storage Temperature Range: -65 ℃ to +150 ℃; (4)Operating Junction Temperature: -55 ℃ to +150 ℃; (5)Input Supply Voltage: -20 to +35V.

Features

LM2931MX-5.0 features: (1)Guaranteed 100mA Output; (2)Fixed Versions 3.3V, 50.V, 8.0; (3)Very Low Quiescent Current; (4)Low Dropout Voltage; (5)Extremely Tight Load and Line Regulation; (6)Very Low Temperature Coefficient; (7)Current and Thermal Limiting; (8)Reverse Battery Protection of -20V; (9)Transient protection of 60V; (10)Output programmable from 3V to 24V.

Diagrams

lm2931mx-5.0 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM2931MX-5.0
LM2931MX-5.0

National Semiconductor (TI)

Low Dropout (LDO) Regulators

Data Sheet

0-2500: $0.22
2500-5000: $0.20
5000-10000: $0.20
LM2931MX-5.0/NOPB
LM2931MX-5.0/NOPB

National Semiconductor (TI)

Low Dropout (LDO) Regulators

Data Sheet

0-1: $0.54
1-25: $0.42
25-100: $0.37
100-250: $0.35
