Product Summary

The DG418BDQ-T1-E3 monolithic CMOS analog switch was designed to provide high performance switching of analog signal. Combining low power, low leakages, high speed, low on-resistance and small physical size, the DG418BDQ-T1-E3 is ideally suited for portable and battery powered industrial and military applications requiring high performance and efficient use of board space.

Parametrics

DG418BDQ-T1-E3 absolute maximum ratings: (1)V-: 20V; (2)V+: 20V; (3)GND: 25V; (4)VL: (GND-0.3) to (V+)+0.3V; (5)Digital Inputs, VS, VD: (V-)-2V to (V+)+2 or 30 mA, whichever occurs first; (6)Current, (Any Terminal) Continuous: 30mA; (7)Current (S or D) Pulsed at 1 ms, 10 % Duty Cycle: 100mA; (8)Storage Temperature: -65 to 150℃; (9)Power Dissipation (Package), 8-Pin Plastic MiniDIPc: 400mW; (10)Power Dissipation (Package), 8-Pin Narrow SOIC mW: 400mW; (11)Power Dissipation (Package), 8-Pin MSOP: 400mW; (12)Power Dissipation (Package), 8-Pin CerDIP: 600mW.

Features

DG418BDQ-T1-E3 features: (1)± 15V analog signal range; (2)On-resistance - RDS(on): 15Ω; (3)Fast switching action - tON: 110ns; (4)TTL and CMOS compatible; (5)MSOP-8 and SOIC-8 package; (6)Compliant to RoHS directive 2002/95/EC.

Diagrams

DG418BDQ-T1-E3 FUNCTIONAL BLOCK DIAGRAM

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DG418BDQ-T1-E3
DG418BDQ-T1-E3

Vishay/Siliconix

Analog Switch ICs Quad Mono CMOS SPST

Data Sheet

0-1: $1.82
1-10: $1.54
10-50: $1.46
50-100: $1.30
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DG411
DG411

Other


Data Sheet

Negotiable
DG411/883
DG411/883

Other


Data Sheet

Negotiable
DG411AK
DG411AK

Maxim Integrated Products

Analog Switch ICs

Data Sheet

Negotiable
DG411AK/883B
DG411AK/883B

Maxim Integrated Products

Analog Switch ICs Quad SPST Normally Closed

Data Sheet

0-1: $16.54
1-25: $16.21
25-50: $14.36
50-100: $13.33
DG411AZ/883B
DG411AZ/883B

Maxim Integrated Products

Analog Switch ICs

Data Sheet

Negotiable
DG411C/D
DG411C/D

Maxim Integrated Products

Analog Switch ICs

Data Sheet

Negotiable
