Product Summary
The SN65HVD05DR combine a 3-state differential line driver and differential line receiver. The SN65HVD05DR designed for balanced data transmission and interoperate with ANSITIA/EIA-485-A and ISO 8482E standard-compliantdevices. The driver is designed to provide a differential output voltage greater than that required by thesestandards for increased noise margin. The drivers and receivers have active-high and active-low enables respectively, SN65HVD05DR can be externally connectedtogether to function as direction control.
Parametrics
SN65HVD05DR absolute maximum ratings: (1)Supply voltage range, Vcc: –0.3V to 6V; (2)Voltage range at A or B: –9V to 14V; (3)Input voltage range at D, DE, R or RE: –0.5V to VCC+0.5V ; (4)Voltage input range, transient pulse, A and B, through 100: –50V to 50V.
Features
SN65HVD05DR features: (1)Minimum Differential Output Voltage of 2.5 VInto a 54-Ω Load ; (2)Open-Circuit, Short-Circuit, and Idle-BusFailsafe Receiver; (3)1/8thUnit-Load Option Available (Up to 256Nodes on the Bus) ; (4)Bus-Pin ESD Protection Exceeds 16 kV HBM ; (5)Driver Output Slew Rate Control Options ; (6)Electrically Compatible With ANSITIA/EIA-485-A Standard ; (7)Low-Current Standby Mode: 1 μA Typical ; (8)Glitch-Free Power-Up and Power-DownProtection for Hot-Plugging Applications ; (9)Pin Compatible With Industry Standard SN75176.
